APPLICATION
Starborn® Structural H19 screws are designed for wood-to-wood connections in a variety of applications including decking, fencing, pergolas, landscape timbers, timber framing, and more. They are fully tested and code compliant alternatives to traditional lag screws and through-bolts, with no pre-drilling required. Structural H19 screws feature a hex washer head for maximum drivability, a unique Tri-Forge® point for reduced driving torque, and a high-adhesion exterior grade coating. The 6? screw is ideal for truss or rafter to top plate connections and is a code compliant alternative to toe-nail connections, metal hurricane ties, and seismic clips.

FEATURES
IRC/IBC code compliant
No pre-drilling
Comparable to 3/8" lag screws
0.19" shank diameter
5/16" hex head for maximum drivability
Tri-Forge® Point provides a fast star, minimal splitting, and reduced driving torque
Speed-Knurl™ reduces friction on the unthreaded shank for faster installation
Black exterior grade coating has high-adhesion and is an ACQ approved alternative to hot-dip galvanized coatings

CODE COMPLIANCE REPORTS
Fastener Properties and Design Values (DrJ TER 1703-05)
Truss or Rafter to Top Plate and Bottom Plate to Rim Board (DrJ TER 1703-02)
